Take Augmented Reality and Automotive Designs to twith the Latest Ansys Zemax Updateshe Next Level

Take Augmented Reality and Automotive Designs to twith the Latest Ansys Zemax Updateshe Next Level

Current trends in augmented reality (AR), automotive, and other high-tech markets and industries are pushing the optics community to design new, innovative products with enhanced performance faster than ever before.

Simulation is critical in optical design because it enables you to accurately model your designs and performance — but that’s not all it does. Ansys Zemax OpticStudio enables you to simulate, optimize, and tolerance your optical designs, while Ansys Zemax OpticsBuilder unites optical and mechanical teams to collaborate on the design of optical products and systems.

Now, with the latest updates in Ansys 2023 R1, both platforms introduce new capabilities that enable you to optimize your designs and performance to greater levels. With upgraded tools and features, you can design and build systems that produce sharper, more accurate images for applications from AR wearables to automotive head-up displays (HUDs).

Create Optics that Stun with Ansys 2023 R1

As technology rapidly develops in consumer electronics, advanced driver assistance systems (ADAS), and other markets, optical design software is enabling companies to deliver cutting-edge innovations that meet increasing consumer demands and expectations. Whatever the application or optical design need, OpticStudio and OpticsBuilder deliver end-to-end solutions, including robust modeling, predictively accurate simulation, and fully customizable analyses.

Today, the optics community has more solutions to add to its tool kit with the latest release of OpticStudio and OpticsBuilder, which includes the following improvements and features available in the noted product editions:

Experience easier integration to Ansys Lumerical FDTD by dynamically linking OpticStudio to the Lumerical rigorous coupled-wave analysis (RCWA) solver for calculating diffraction efficiency (when Lumerical is installed on the same computer). With this feature, you can simulate and optimize complex 2D gratings used in advanced AR and HUD systems.

Easily create and tolerance complex surface geometries in sequential mode, including direct tolerancing of irregularities on sag-based and stacked composite surfaces without requiring workarounds by utilizing the latest composite surface capabilities in OpticStudio. With this feature, you can add multiple sag profiles to achieve an optical surface with a complex new sag distribution as desired. Similarly, if you want to add several types of sag distributions to one surface, you can add multiple surfaces as a composite stack.
